Programming the Mio R-4
33
Mio Modero R-4 Remote
Border Styles by Numbers
Border styles can be used to program borders on buttons, sliders, and popup pages.
The TPDesign4 Touch Panel Design program has pre-set border styles that are user selectable.
You cannot use the following number values for programming purposes when changing border styles. TPD4 border
styles can ONLY be changed by using the name.
Border Styles by Numbers
No. Border styles No. Border styles
0-1 No border 10-11 Picture frame
2 Single line 12 Double line
3 Double line 20 Bevel-S
4 Quad line 21 Bevel-M
5-6 Circle 15 22-23 Circle 15
7 Single line 24-27 Neon inactive-S
8 Double line 40-41 Diamond 55
9 Quad line
TPD4 Border Styles by Name
No. Border styles No. Border styles
1 None 22 Circle 155
2 AMX Elite -L 23 Circle 165
3 AMX Elite -M 24 Circle 175
4 AMX Elite -S 25 Circle 185
5 Bevel -L 26 Circle 195
6 Bevel -M 27 Cursor Bottom
7 Bevel -S 28 Cursor Bottom with Hole
8 Circle 15 29 Cursor Top
9 Circle 25 30 Cursor Top with Hole
10 Circle 35 31 Cursor Left
11 Circle 45 32 Cursor Left with Hole
12 Circle 55 33 Cursor Right
13 Circle 65 34 Cursor Right with Hole
14 Circle 75 35 Custom Frame
15 Circle 85 36 Diamond 15
16 Circle 95 37 Diamond 25
17 Circle 105 38 Diamond 35
18 Circle 115 39 Diamond 45
19 Circle 125 40 Diamond 55
20 Circle 135 41 Diamond 65
21 Circle 145 42 Diamond 75
43 Diamond 85 85 Menu Bottom Rounded 65
44 Diamond 95 86 Menu Bottom Rounded 75
45 Diamond 105 87 Menu Bottom Rounded 85
46 Diamond 115 88 Menu Bottom Rounded 95
47 Diamond 125 89 Menu Bottom Rounded 105
48 Diamond 135 90 Menu Bottom Rounded 115
49 Diamond 145 91 Menu Bottom Rounded 125
50 Diamond 155 92 Menu Bottom Rounded 135

AMX MIO-R4 Specifications

General

Flash memory	32 MB
RAM capacity	64 MB
Certification	FCC, IC, CE, IEC 60950, Japan Approval
Maximum range	30 m
Frequency band	2.4 GHz
Languages support	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, HUN, ITA, JPN, KOR, POR, RUS, THA
Number of devices supported	2
Interface	IR Wireless
Input type	Press buttons
Hard buttons	Yes
Product color	Black
Buttons quantity	29
Remote control proper use	-
Display diagonal	2.4 \
Display resolution	240 x 320 pixels
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Package weight	25 g

Weight and Dimensions

Depth	19 mm
Width	51 mm
Height	240 mm
Weight	20 g
