NI-3101-SIG Signature Series NetLinx Integrated Controller
NI-3101-SIG Specifications (Cont.)
Rear Panel Connectors
(Cont.):
AXlink LED • Green LED indicates the state of the AXlink connector port.
• Normal AXlink activity = 1 blink/second
• Abnormal AXlink activity = cycle of 3 consecutive blinks and then Off
AXlink port • 4-pin 3.5 mm mini-Phoenix (male) connector provides data and power to
external control devices.
Power port • 2-pin 3.5 mm mini-Phoenix (male) connector
Included Accessories: • 2-pin 3.5 mm mini-Phoenix (female) PWR connector (41-5025)
• 4-pin 3.5 mm mini-Phoenix (female) AXlink connector (41-5047)
• 10-pin 3.5 mm mini-Phoenix (female) I/O connector (41-5107)
• Installation Kit (KA2105-02):
Two rack mount ears
Four #8-32 Phillips flat head screws
• NI-3101-SIG Quick Start Guide (93-2105-08)
• Two 8-pin 3.5 mm mini-Phoenix (female) Relay connectors (41-5083)
• Two CC-NIRC IR Emitters
Other AMX Equipment: • 2-pin 3.5 mm mini-Phoenix male connector (41-5026)
• CC-NIRC IR cables (FG10-000-11)
• CC-NSER IR/Serial cables (FG10-007-10)
• CSB Cable Support Bracket (FG517)
• NCK, NetLinx Connector Kit (FG2902)
• USB A to B cable (FG10-2105)
