NetLinx Programming
114
TPI-PRO-DVI - Instruction Manual
Embedded Codes
The following is a list of G4 compatible embedded codes:
Input Commands (Cont.)
^SLT (Cont.) ?Resolution: Query the detected resolution for an input.
Syntax:
?resolution
The TPI will respond with a DATA COMMAND event from port 1 of the panel. The DATA.TEXT of the event will be in the
following format.
'^SLT-<slot number 1-4>,resolution=<detected resolution string>'
Example:
SEND_COMMAND TP,"'^SLT-1,?resolution'"
Queries input 1 for the current input resolution. Panel will respond with a DATA Command event.
Command data will vary depending on input type and detected resolution.
• For composite and svideo: NTSC, PAL, …, No Signal Detected
• For component, RGB, and DVI: <Horz>x<Vert>@<Ref> <desc>, No Signal Detected, or Manual:
<Horz>x<Vert>@<Ref> <desc>
^VKS Send one or more virtual keystrokes to the G4 application. Key presses and key releases are not distinguished except in the
case o f C TRL , A LT, a n d SHI F T. The Embedded Codes section on page 114 defines special characters which can be included
with the string, but may not be represented by the ASCII character set.
Syntax:
"'^VKS-<string>'"
Variable:
• string = Only 1 string per command/only one stroke per command.
Example:
SEND COMMAND Panel,"'^VKS-'8"
Sends out the keystroke 'backspace' to the G4 application.
Embedded Codes
Decimal numbers Hexidecimal values Virtual keystroke
8 ($08) Backspace
13 ($0D) Enter
27 ($1B) ESC
128 ($80) CTRL key down
129 ($81) ALT key down
130 ($82) Shift key down
131 ($83) F1
132 ($84) F2
133 ($85) F3
134 ($86) F4
135 ($87) F5
136 ($88) F6
137 ($89) F7
138 ($8A) F8
139 ($8B) F9
140 ($8C) F10
141 ($8D) F11
142 ($8E) F12
143 ($8F) Num Lock
144 ($90) Caps Lock
145 ($91) Insert
146 ($92) Delete
147 ($93) Home
148 ($94) End
149 ($95) Page Up
150 ($96) Page Down
151 ($97) Scroll Lock
152 ($98) Pause
153 ($99) Break
154 ($9A) Print Screen
155 ($9B) SYSRQ
156 ($9C) Tab
