Appendix A: Supported Input and Output Modes
155
TPI-PRO-DVI - Instruction Manual
Appendix A: Supported Input and Output Modes
Overview
This section lists the supported Input and Output modes for the TPI-PRO-DVI.
Supported Input Modes
Use the ^SLT Input Command to manually specify the input mode (see ^SLT on page 103).
Supported Input Modes - DVI and RGB
The following table lists the supported input modes for DVI and RGB:
Supported Input Modes for DVI and RGB
Resolution Standard Resolution Standard
640x350@85 VESA-DMT 1280x768@75 VESA-CVT
640x400@60 VESA-CVT 1280x768@85 VESA-CVT
640x400@85 VESA-DMT 1280x800@60 VESA-CVT
640x480@60 VESA-DMT 1280x960@60 VESA-DMT
640x480@72 VESA-DMT 1280x960@85 VESA-DMT
640x480@75 VESA-DMT 1280x1024@60 VESA-DMT
640x480@85 VESA-DMT 1280x1024@75 VESA-DMT
720x400@85 VESA-DMT 1280x1024@85 VESA-DMT
720x480@60 480p CEA 861 1360x764@60 VESA-CVT
720x576@50 576p CEA 861 1360x768@60 VESA-DMT
800x500@60 VESA-CVT 1400x1050@60 VESA-CVT
800x600@56 VESA-DMT 1400x1050@60 rb VESA-CVTR
800x600@60 VESA-DMT 1400x1050@75 VESA-CVT
800x600@72 VESA-DMT 1440x900@60 VESA-CVT
800x600@75 VESA-DMT 1440x900@60 rb VESA-CVTR
800x600@85 VESA-DMT 1440x900@75 VESA-CVT
848x477@60 VESA-CVT 1440x900@85 VESA-CVT
848x480@60 VESA-DMT 1600x1200@60 VESA-DMT
848x480@75 VESA-CVT 1680x1050@60 VESA-CVT
848x480@85 VESA-CVT 1680x1050@60 rb VESA-CVTR
1024x640@60 VESA-CVT 1920x540@50 1080i CEA 861
1024x768@60 VESA-DMT 1920x540@50 1080i_S295M CEA 861
1024x768@70 VESA-DMT 1920x540@60 1080i CEA 861
1024x768@75 VESA-DMT 1920x1080@24 1080p CEA 861
1024x768@85 VESA-DMT 1920x1080@25 1080p CEA 861
1152x864@75 VESA-DMT 1920x1080@30 1080p CEA 861
1280x720@50 720p CEA 861 1920x1080@50 1080p CEA 861
1280x720@60 VESA-CVT 1920x1080@60 VESA-CVT
1280x720@60 rb VESA-CVTR 1920x1080@60 1080p CEA 861
1280x720@60 720p CEA 861 1920x1080@60 rb VESA-CVTR
1280x768@60 rb VESA-CVTR 1920x1200@60 VESA-CVT
1280x768@60 VESA-CVT 1920x1200@60 rb VESA-CVTR
