MAXREFDES106# Health Sensor Platform 4.0
Push Button Description
Table 1 describes the functionality of the push button. For non-power related button presses ‘Status LED’
activity and push button functions start two seconds after the last push button press and release (timeout
for number of presses counter is 2s).
Table 1. Push Button Functionality
Push Button Action
Status LED Activity
Function When Released
During Press
2s After Release
Press for > 1 Second
Off
On with Status
Power On
Press for > 3 Seconds
No Change
Off
Power Off
Press for > 13 Seconds
No Change
Off
Force Power Off
Once Powered Up
1 Press in 2 Seconds
No Change
Flashing Green When
Successful
Start/Stop Location Finder (2s
After Release)
2 Presses in 2 Seconds
No Change
Slow Blink Cyan
Start/Stop Flash Logging
(2s After Release)
3 Presses in 2 Seconds
No Change
Off
Turn Off/On Status LED
(2s After Release)
Color Definitions for the Status LED
Table 2 describes the state of the device for a given ‘Status LED’ color and blinking status. These are listed
in order of priority. As an example, if a failure is detected (solid red LED), this has higher priority and is
displayed instead of a yellow LED status.
Table 2. Color
Definitions for
Status LED (When
Location Finder is
Inactive) LED
Color
Solid (No
Blinking)
Fast Blink
Slow Blink
Green
Not Used
Location Finder Successful
Not Used
Blue
Bluetooth
Connected
Not Used
GUI Logging Using BLE
in Progress
Red
Failure Detected
MAX32674C Communications
Failed
Battery Critically Low
(<10%)
Yellow
Device is
Initializing
MAX32674C Programming in
Progress
Battery Low
(10% to 50%)
Cyan
USB Connected
Not Used
Flash Logging in
Progress
Pink
Not Used
Not Used
Battery High (>50%)
