Updating the MAX32674C Algo Hub Microcontroller Coprocessor Firmware (.msbl)
1. Connect the USB-C cable to the MAXREFDES106# and connect the other end of the
cable (USB-A end of the USB-C) to the PC USB port.
Figure 7. Connect USB-C Cable to the MAXREFDES106#
2. Open the ‘Device Manager’ and note the COM port associated with the
MAXREFDES106#.
Figure 8. Note the USB Serial Device COM Port Number for MAXREFDES106#
3. Navigate to the MAX32674C firmware subfolder of the MAXREFDES106# software
package.
4. Double click the Flash_MAX32670_MRD106.bat file (not the .exe file). A command prompt
opens and asks for a port number. Enter the COM port number from step 3 and press ENTER.
Only the port number is needed here (that is, for COM6, enter 6).
Figure 9. Note the USB Serial Device COM Port Number
5. After pressing ENTER, the program begins flashing the MAX32674C with the latest
firmware. A successful flash looks like Figure 10, and ‘SUCCEED…’ displays near the end.
