MAXREFDES106# Health Sensor Platform 4.0
Available Options
Table 2. Location Finder Configuration Options
Sub-Section
Option
Description
Chest SpO2 Location
Finder Tool
CH1: Red/IR
Color Indicator
MAXREFDES106# has two optical channels (Red and
IR in each channel) to evaluate the optimal location on
the chest. Green is for great location, yellow is for okay
location, and red for poor location.
CH2: Red/IR
Color Indicator
MAXREFDES106# has two optical channels (Red and
IR in each channel) to evaluate the optimal location on
the chest. Green is for great location, yellow is for okay
location, and red is for poor location.
Start/Stop
Start/Stop the location finder algorithm.
Auto Stop Upon
Successful
Location
Selects to automatically stop the location finder
algorithm when an optimal location is found.
PLL Tab
The PLL tab allows the generation of PLL clock frequency. PLL is enabled by default. PLL frequency is
generated by multiplying the Clock Selection frequency with the M Divider. PLL frequency ranges from
4MHz to 24MHz. Refer to Table 3 for more details.
