MAXREFDES106# Health Sensor Platform 4.0
Table 15. Options for BIA
Sub-Section
Option
Description
BIA
Units of
Measurement
Select ‘Metric’ or ‘Imperial’ units when using BIA.
Height, Weight, Age
Enter your height, weight, and age into the Bioelectrical
Impedance Inputs window.
Gender
Select ‘Male’ or ‘Female’ in the ‘Gender’ window.
Temperature Tab
The temperature tab is used to start, stop, and plot skin and ambient temperature measurements from
the onboard MAX30210 clinical grade 0.1ºC accurate temperature sensor, calibrated in an oil bath. See
the available options in Table 16 for more details.
Figure 65. Temperature Tab
