MAXREFDES106# Health Sensor Platform 4.0
Figure 67. Registers Tab
Available Options
Table 17. Registers Configuration Options
Sub-Section
Option
Description
Registers
Device
Select the device registers to read/write to the MAX86178,
MAX30210, or ADXL367.
MAX86176
The MAX86178 is fully adjustable through software registers and
the user can read/write to the register.
MAX30210
The MAX30210 also has the flexibility to get controlled by
registers and the user can read/write to the register.
ADXL367
This is an accelerometer with certain info and control registers the
user can control.
