58
05/2008 Rev. 0.6
Service menu continued….
Main item Sub item Sub Range Description
2.7 Hardware test Inputs Temperature Boiler temp
Shows the status of the sensors/switches
indicated
Level sensors High Yes/no
Low Yes/no
Drip tray sensor Yes/no
Waste bin Yes/no
Door switch Yes/no
Brewer switch Yes/no
Key switch Yes/no
Outputs
Test by holding
in recipe button
11.
# During test the
display shows
the Nominal
current (mA)
When the
Nominal current
of a output rises
above the set
current *
mentioned output
will be shut off.
Caution: BM 1
goes through a
complete drinks
cycle.
KW1
* 400 mA
Inlet valve (Boiler)
DV1 Dispenser valve 1 (Brewer)
DV2 Dispenser valve 2 (Mixer 2)
DV3 Dispenser valve 3 (Mixer 3)
DV4 Dispenser valve 4 (Hot water)
DV5 Dispenser valve 5 (n/a)
DV6 Inlet valve 6 (Cold water) optional!
IM1 #
* 400 mA
Ingredients motor 1 (Canister 1)
IM2 # Ingredients motor 2 (Canister 2)
IM3 # Ingredients motor 3 (Canister 3)
IM4 # Ingredients motor 4 (Canister 4)
IM5 # Ingredients motor 5 (Canister 5)
IM6 # Ingredients motor 6 (Canister 6)
BM/MM1 #
* 800 mA
Brewer motor
MM2 # Mixer motor 2
MM3 # Mixer motor 3
Ventilator * 200 mA Ventilator
LED’s LED’s
Calib. valves
Test by holding
in recipe button
11 (for 1 sec.)
to open the rel-
evant valve for
10 seconds.
DV1 15 ml / sec Calibrate to 150 ml (10 sec x 15 ml)
DV2 15 ml / sec Calibrate to 150 ml (10 sec x 15 ml)
DV3 15 ml / sec Calibrate to 150 ml (10 sec x 15 ml)
DV4 20 ml / sec Calibrate to 200 ml (10 sec x 20 ml)
DV5 20ml / sec. Calibrate to 200ml (10sec. x 20ml)
(Optional valve for Brewer By-pass)
DV6 42 ml / sec Inlet valve cannot be calibrated (fixed flow)
