Page 93
Right Speaker Post 8 Ohm Wiring
Similarly, make the connections from the Right output transformer to the Right speaker posts.
Left Speaker Post 4 Ohm Wiring
Cut
just the exposed end
of the Purple wire cleanly and cover it with a small plastic wire
connector, and tuck it between the transformer and the front of the chassis.
Route the Blue and Green wires from the Left output transformer between the 2 transformers,
behind the Right transformer, and route the 4 wires along the outside of the chassis alongside the
Mains Secondary wires (use cable ties and/or heatshrink to keep them together neatly.
Connect the Blue wire coming from the Left output transformer to the Left Red speaker post.
Connect the Green wire coming from the Left output transformer to the Left Black speaker post.
Right Speaker Post 4 Ohm Wiring
Similarly, make the connections from the Right output transformer to the Right speaker posts.
