Re marks: Saves the con figu ra tion of the power me ter into the mem ory lo ca tion
speci fied. Sen sor Setup, Chan nel Setup, and Trig ger Setup are saved
along with all other in stru ment pa rame ters.
Re lated
Com mands: *RCL
*SRE Setup serv ice re quest en able reg is ter
GPIB 488.2
Syn tax: *SRE <val>
val: 8- bit mask
Re marks: Sets the Serv ice re quest en able reg is ter bits.
*SRE? Re turn Serv ice Re quest En able reg is ter
GPIB 488.2
Syn tax: *SRE?
Re marks: Re turns the Serv ice Re quest En able reg is ter.
*STB? Re turn Status Byte reg is ter
GPIB 488.2
Syn tax: *STB?
Re marks: Re turns the status byte value with bit 6 re placed with the MSS value.
MSS is the GPIB Mas ter Sum mary Status, and in di cates that the de vice
has at least one rea son for re quest ing serv ice. Al though the MSS mes -
sage is sent in bit po si tion 6 of the de vice’s re sponse to the *STB? query,
it is not sent in re sponse to a se rial poll and should not be con sid ered
part of the IEEE 488.1/2 status byte. MSS = the Status Byte (STB)
OR`ed with the Serv ice Re quest En able reg is ter (SRE). Un like the
*ESR? Com mand, this com mand does not clear the reg is ter af ter wards.
*TRG Per form the GPIB 'Group Exe cute Trig ger' com mand
GPIB 488.2
Syn tax: *TRG
Re marks: Per forms a 'GET' com mand. The GT0, GT1 and GT2 commands set the
response to the GET or *TRG com mands. When the ML2400 Series is
triggered using this com mand or the 488.1 hard ware trigger, a trigger
and output for each display channel that is not OFF gives a response in
the output queue. If both display channels are dis played, there will be
two messages in the output queue to be read out.
6-16 ML2400A OM
ML24XXA NATIVE COMMANDS GPIB OPERATION
