GRDATA Dis play Graph Cur sor Data PRO FILE SETUP
Syn tax: GRDATA <state>
state: ON or OFF
Re marks: Dis play the graph cur sor data read out box. GRDATA must be turned on
be fore at tempt ing to execute the GRDRQ command to send the data
over the GPIB. If GRDATA is not on, GRDRQ will produce an execution
error in the event status reg is ter (ESR).
Re lated
Com mands: GRDRQ
Query: GRDATA?
Re turned
String: GRDATA <state>
GRDDT Power vs. Time data dis play time
SYSTEM
Syn tax: GRDDT <time>,<units>
time: 1 minute to 24 hours (1440 min utes)
units: MIN (min utes)
HR (hours)
Re marks: Sets the time pe riod of the x axis in min utes or hours. For ex am ple, ei -
ther of the fol low ing state ments may be used to set the time pe riod to
2.5 hours:
GRDDT 2.5,HR
GRDDT 150,MIN
Query: GRDDT?
Re turned
String: GRDDT <time>,<units>
GRDRQ Re turn Graph Data read out
DATA OUT PUT
Syn tax: GRDRQ
Re marks: Re turns the val ues in the graph data box. GRDATA must be turned on
be fore at tempt ing to execute GRDRQ . The re sult string is:
GRDRQ <chan nel_number>,<Cur sor_1_dB>,<Cur -
sor_2_dB>,<Delta_power>,<Delta_time>[,<Av er age>]
6-42 ML2400A OM
ML24XXA NATIVE COMMANDS GPIB OPERATION
