Re marks: When the sys tem trig ger in pro file mode is set to ei ther INTA or INTB
(in ter nal sen sor A or B) it will trig ger on a power level given by the sen -
sor. This com mand sets the level.
Re lated
Com mands: GTSRC , GTTYP
Query: GTLVL?
Re turned
String: GTLVL <val>
GTSRC Set Pro file Trig ger source
TRIG GER
Syn tax: GTSRC <source>
source: INTA
INTB
EXTTTL
MAN UAL
CONT
Re marks: INTA = in ter nal sen sor A
INTB = in ter nal sen sor B
EXTTTL = ex ter nal BNC TTL trig ger in put
MAN UAL = man ual push but ton trig ger
CONT = con tinu ous
MAN UAL trig ger only func tions cor rectly on non- repetitive sam pling,
i.e., the PRO FILE PE RIOD needs to be 6ms or greater.
The dis play shows an ‘x’ mark ing the trig ger point. This trig ger point
mark ro tates as the pro file data is up dated, chang ing be tween 'x' and '+'
on each data up date. On rapid up dates, the trig ger point mark may ap -
pear like a star (*), as it is ro tat ing so quickly. In man ual, ex ter nal or
GPIB trig gered dis plays, the mark ro tates at a slower rate and each true
data up date can be seen.
The GTSRC set ting is over rid den by the Group Ex e cute Trig ger GPIB
com mon com mand (GET), * TRG , TR0, TR1 and TR2 com mands. The
TR3 com mand will re turn the sys tem to its pre vi ous state if the TR0
(Trig ger hold) com mand has been used.
Query: GTSRC?
Re turned
String: GTSRC <source>
ML2400A OM 6-49
GPIB OPERATION ML24XXA NATIVE COMMANDS
