c: 1 or 2
state: ON or OFF
Re marks: The LLIMS com mand turns the lim its on and off.
Re lated
Com mands: LLIM
Query: LLIMS? <c>
Re turned
String: LLIMS <c>,<state>
MMRST Min Max Track ing re set
CHAN NEL
Syn tax: MMRST <c>
c: 1 or 2
Re marks: This com mand re sets the min/max val ues when in 'Read out' or 'Power
vs. Time' mode. In pro file mode, this com mand is used to re set the chan -
nels min/max val ues. If in CDMA read out mode and the chan nel is in
Peak or Crest, this com mand will clear the chan nels peak or crest mea -
sure ment.
MNGDB Out put Min Graph Bi nary Data
DATA OUT PUT
Syn tax: MNGDB
Re marks: Avail able in graph modes only. Out puts in bi nary form the min graph
data to the GPIB in the long in te ger form of 1024 bits per dB as a def i -
nite length ar bi trary block re sponse data. The C pro gram ming ex am ple
'Bi nary out put de cod ing' on page 6-136 shows how to ex tract the bi nary
data. The re sponse form is as fol lows :
MNGDB <#><length><num -
ber_of_bytes><data_byte_1><data_byte_2> ...<data_byte_n><\n>
<length> num ber of ASCII char ac ters make up the num ber_of_bytes
value
<num ber_of_bytes> num ber of bytes of data con tained in rest of the
string
<data_byte_n> four of these val ues makes up the long in te ger.
For ex am ple: FF FF D1 64 = –11932 As it is based on 1024 per dB, di -
vide by 1024 to get the dB value (–11.652).
MNGD Out put Min Graph Data
DATA OUT PUT
Syn tax: MNGD
6-54 ML2400A OM
ML24XXA NATIVE COMMANDS GPIB OPERATION
