<state>:
If state is FALSE, no data fol lows be cause there are no valid re sults for
this sen sor avail able.
If state is TRUE, the re sults for the se lected sen sor are dis played in the
fol low ing or der:
zero value, range 1 up per, range 1 lower, range 2 up per, range 2 lower,
range 3 up per, range 3 lower, range 4 up per, range 4 lower, range 5 up -
per, range 5 lower.
RDMODE Read out Mode selection
SYSTEM
Syn tax: RDMODE <mode>
mode: STAND
CDMA
Re marks: Se lects Stan dard or CDMA Read out mode. When CDMA is se lected, a
CDMA mode activ e mes sage will be dis played on the top line of the dis -
play.
Query: RDMODE?
Re turned
String: RDMODE <mode>
REL Rela tive con trol
CHAN NEL
Syn tax: REL <c>,<mode>
c: 1 or 2
mode: 0 Turn OFF
1 Turn ON and ref er ence
2 Turn ON, use old ref er ences if not first time.
Re marks: Turns rel a tive ON or OFF, or ref er ences the zero point.
REL1 and REL2 tog gle be tween rel a tive and ab so lute mea sure ments.
Sending the RELx com mand when in dB mode will make the me ter ap -
ply the last used REL A TIVE value. This rel a tive value is used there af ter
un til it is re placed by an other one in the same man ner. This al lows the
user to re fer to a pre vi ously ref er enced value, with out the me ter re set -
ting it self back to a 0.00 dis play.
Query: REL? <c>
Re turned
String: REL <c>,<mode>
ML2400A OM 6-69
GPIB OPERATION ML24XXA NATIVE COMMANDS
