U = Sen sor B low level av er age: '0' = OFF, '1' = Low, '2' = Me dium, '3' =
High.
V = Sen sor A ze roed sta tus: '0' = Not ze roed, '1' = Zeroed.
W = Sen sor B Zeroed sta tus: '0' = Not ze roed, '1' = Zeroed.
X = GPIB trig ger mode: '0' = TR0 hold ON, '1' = Free run.
Y = GPIB group trig ger mode: '0' = GTO, '1' = GT1, '2' = GT2.
Z = Cal i bra tor state: '0' = OFF, '1' = ON.
1 = GPIB DISP com mand sta tus: '0' = OFF, '1' = ON.
2 = GPIB FAST sta tus: '0' = OFF, '1' = ON.
STERR Re turns re sults of POST or *TST?
DATA OUT PUT
Syn tax: STERR
Re marks: Re turns (<sp> = space):
'FLASH<sp>0xnnnn,CALDAT<sp>0xnnnn,PER -
SON<sp>0xnnnn,RAM<sp>0xnnnn,NON -
VOL<sp>0xnnnn,LCD<sp>0xnnnn,KBD<sp>0xnnnn,DSP<sp>0xnn
nn/n'
FLASH check sum test: 0x0000 = Passed, 0xffff = Failed
CALDAT check sum test: 0x0000 = Passed, 0xffff = Failed
PER SON al ity data: 0x0000 = Passed, 0xffff = Failed
RAM read/write test: 0x0000 = Passed, 0xffff = Failed
NON VOL RAM test: 0x0000 = Passed, 0x0001 = Soft ware ver sion fail,
0x0002 = Cur rent store fail, 0x0004 = Saved store fail, 0x0008 = se cure
mode fail, 0xffff = read fail ure
LCD mem ory test: 0x0000 = Passed, 0xffff = Failed
KBD stuck key test: 0x0000 = Passed, 0xffff = Failed
DSP test: 0x0000 = Passed, else FA TAL er ror
Re lated
Com mands: START, CONT
SYSLD Load saved setup store over the GPIB
DATA OUT PUT
Syn tax: SYSLD <store number>, <data length>, <bi nary data>
6-76 ML2400A OM
ML24XXA NATIVE COMMANDS GPIB OPERATION
