Anritsu ML2480B Series Maintenance Manual

1-10 Test Equipment List Chapter 1 — General Information
1-6 PN: 13000-00164 Rev. K ML248xx, ML249xA MM
1-10 Test Equipment List
Table 1-12 provides a list of recommended test equipment needed for the performance verification, calibration,
and troubleshooting procedures presented in this manual. The test equipment setup is critical to making
accurate measurements. In some cases, you may substitute test equipment having the same critical
specifications as the test equipment indicated in the test equipment list (refer to“Measurement Uncertainty”
on page 3-1).
Table 1-11. ML249xA Spare Parts
Description ML249xA Part No
PSU for ML249xA ND61153
Measurement PCB assembly for ML2495A ND65068
Measurement PCB assembly for ML2496A ND65069
Control PCB for ML249xA ND65070
Front panel assembly all cables and overlay fitted ML2495A. ND65071
Front panel assembly all cables and overlay fitted ML2496A. ND65072
Top Case with gaskets ND50266
Bottom Case with gaskets ND50267
Rear panel assembly for ML249xA ND65073
TCPIP Embedded stack assembly ND65074
1 GHz Calibrator Exchange Assy ND69837
ML248xx/9xA RF 1 GHz Calibrator Cable 62212
ML2495A Single Channel Flexi Cable ND68098
ML2496A Dual Channel Flexi Cable ND68099
Note Other assemblies may be added if required.
Table 1-12. Test Equipment List (1 of 2)
Instrument Critical Specification Manufacturer/Model Usage
(a)
Range Calibrator N/A Anritsu ML2419A C, P
Frequency Counter Anritsu MF2412B C, P
RF Cable:
BNC male connector at one end and
N-type male connector at other end
BNC(m) to N(m) Any common source C, P
RF Cable:
N-type male connection at both ends
N(m) to N(m) Any common source C, P
BNC male to dual binding post
adaptor
N/A Any common source P
Analog Power Meter
Functions with Agilent Nano Volt
meter and Agilent 8478B
Agilent 432A C, P
Power Meter Functions with Agilent 8478B Agilent N432A P
S820E
VNA to measure VSWR at 50 MHz
and 1 GHz
Anritsu P
Nano Volt / Micro Ohm Meter or
equivalent
Functions with Agilent 432A power
meter.
Agilent 34420A C, P
