Anritsu ML2480B Series Maintenance Manual

A-3 Test Records Appendix A — Test Records
A-2 PN: 13000-00164 Rev. K ML248xx, ML249xA MM
ML248xx, ML249xA Firmware Revision: Operator:
Serial Number: Date: Options:
Section 3-4: Input Range Verification
Measurements and Calculated Error Figure
Range
Measured
(dB)
Channel A
Measured
(dB)
Channel B
Expected
Level
Error (dB)
(Meas–Expected)
CH A
Error (dB)
(Meas–Expected)
CH B
Range 1 Upper Level
–0.9540 dB
Range 1 Lower Level
–11.8342 dB
Range 2 Upper Level
–11.8342 dB
Range 2 Lower Level
–25.7741 dB
Range 3 Upper Level
–25.8606 dB
Range 3 Lower Level
–41.8031 dB
Range 4 Upper Level
–41.8031 dB
Range 4 Lower Level
–57.8139 dB
Range 5 Upper Level
–57.8139 dB
Range 5 Lower Level
–61.7260 dB
Range 7 Upper Level
(ML2487/8B & ML249xA)
–0.9540 dB
Range 7 Lower Level
(ML2487/8B & ML249xA)
–11.8342 dB
Range 8 Upper Level
(ML2487/8B & ML249xA)
–11.8342 dB
Range 8 Lower Level
(ML2487/8B & ML249xA)
–16.8965 dB
Range 9 Upper Level
(ML2487/8B & ML249xA)
–16.8965 dB
Range 9 Lower Level
(ML2487/8B & ML249xA)
–25.7741 dB
RF Calibrator Output 0 dBm
Specification Level Error Pass/Fail
± 0.03 dBm
