Anritsu ML2480B Series Maintenance Manual

A-3 Test Records Appendix A — Test Records
A-12 PN: 13000-00164 Rev. K ML248xx, ML249xA MM
ML248xx, ML249xA Firmware Revision: Operator:
Serial Number: Date: Options:
Section 4-5: DC Reference Calibration
Voltage Test Points DSP Cal 6 Measurement
DSP Cal 5 Measurement
After Adjustment
Specification
ZTP17 (gnd) and ZTP205 (+V)
______________VDC ______________VDC DSP6 = DSP5 ± 2mV
Section 4-6: RF Calibrator 50 MHz Frequency Adjustment
(ML248xx without Option 15)
Measured
(After Adjustment of L12)
Specification
Frequency
______________MHz 50 MHz ± 500 kHz
Section 4-7: RF Calibrator Output Power Adjustment
(ML248xx without Option 15)
Measured Specification
P
actual
Lower = ______________mW
P
actual
Upper = ______________mW
1 mW ± 0.0015 mW
