Chapter 1 General Information
Channel Scanner (Option 27)
Frequency Range: 100 kHz to 3.0 GHz
Frequency Accuracy: ± 10 Hz + Time base error, 99% confidence level|
Measurement Range: +20 dBm to –110 dBm
Channel Power: ± 1 dB typical (± 1.5 dB max)
Adjacent Channel Pwr Accuracy: ± 0.75 dBc
Power Meter (Option 29)
Frequency Range: 3 MHz to 3000 MHz
Detection Range: –80 dBm to +80 dBm
Offset Range: 0 to +60 dB
Accuracy: ± 1 dB typical (± 1.5 dBm max), ³10 MHz to 3 GHz
±2 dB, typical, 3 MHz to <10 MHz
VSWR: 1.5:1 typical (P
in
> –30 dBm, 10 MHz to 2.4 GHz)
Maximum Input Power
without damage: +43 dBm without external attenuator
GPS (Option 31)
GPS Location Indicator
Latitude, Longitude and Altitude on Display
Latitude, Longitude and Altitude with Trace Storage
T1 Analyzer (Option 50, S331D only)
Line Coding: AMI, B8ZS
Framing Modes: D4 (Superframe), ESF (Extended Superframe)
Connection Configurations: Terminate (100W)
Bridge (³ 1000W)
Monitor (Connect via 20 dB pad in DSX)
Receiver Sensitivity: 0 to –36 dBdsx
Transmit Level: 0 dB, –7.5 dB, and –15 dB
Clock Sources: External
Internal: 1.544 MHz ± 30 ppm
Pulse Shapes: Conform to ANSI T1.403
Pattern Generation & Detection: PRBS: 2-9, 2-11, 2-15, 2-20, 2-23 Inverted and non-inverted,
QRSS, 1-in-8 (1-in-7), 2-in-8, 3-in-24, All ones, All zeros,
T1-Daly, User defined (£ 32 bits)
Circuit Status Reports: Carrier present, Frame ID and Sync., Pattern ID and Sync.
Alarm Detection: AIS (Blue Alarm), RAI (Yellow Alarm)
Error Detection: Frame Bits, Bit, BER, BPV, CRC, Error secretary
Error Insertion: Bit, BPV, Framing Bits, RAI, AIS
Loopback Modes: Self loop, CSU, NIU, user defined, In-band or Data Link
Level Measurements: Vp-p (± 5%), dBdsx
Data Log: Continuous, up to 48 hrs
Table 1-1. Performance Specifications (4 of 6)
