2A.2 Nameplate
The following is an example of the nameplate. This can be found on every GT3000 drive. It shows the rated values.
GT3000 AC power supply GT3000 DC power supply
1
2-3
4-5-6
7-8
9-10-11
12-13
14
15-16-17
18-19
20
21-22
23
24
25
1 Drive type
2 Serial number
3 Product test date
4 Input voltage
5 Input frequency (for AC supply only)
6 Number of input phases (for AC supply only)
7 Input current
8 Maximum symmetrical short circuit current
9 Auxiliary Input voltage
10 Auxiliary Input frequency
11 Auxiliary Number of input phases
12 Auxiliary Input current
13 Notes
14 Rated output [kVA]
15 Output voltage
16 Output frequency
17 Number of output phases
18 Output power KW (Cl.1)
19 Output power HP (Cl.1)
20 Output current (Cl.1)
21 Output power KW (Cl.2)
22 Output power HP (Cl.2)
23 Output current (Cl.2)
24 Operating temperature
25 SAP code
Figure 2A.2. Nameplate
