2A.8 Standards
EN 60 146-1-1 Semiconductor converters - General requirements and line commutated converters.
Part 1-1: Specification of basic requirements.
EN 60 146-1-2 General instructions and line commutated converters.
Part 1-2: Application guide.
Semiconductor converters.
Part 2: Self-commutated semiconductor converter including direct D.C. converters.
EN 60 204-1 Safety of machinery. Electrical equipment of machines. Part 1:
General requirements. Provisions for compliance: The final assembler of the machine is responsible for
installing: an emergency-stop device and a supply disconnecting device
EN 60 204-1
Amendment 1
Electrical equipment of industrial machines.
Part 2: use of components and examples of drawings, diagrams, tables and instructions.
EN 60 529: 1991 Degrees of protection provided by enclosures (IP code)
EN 60664-1 (1992) Isolation coordinated for appliances in low-voltage systems.
Part 1: Principles, requirements and tests.
EN 61 800-3 (1996) +
Amendment A11 (2000)
EMC product standard including specific test methods. (EMC product standard)
EN 50 178 Electronic equipment for use in power installations.
CE Marking
GT3000 drives bear the CE marking. It shows that the product is conforming to the European Directive 2006/95/EC
called “Low Voltage Directive” and to the Directive.89/336/EC as amended by 93/68/EEC called EMC Directive.
CE marking is valid for EMC provided GT3000 drives are used in accordance with this manual instructions.
UL certification
Drives GT3000 are certified for the US and Canadian market.
The file number of Answer Drives
S.r.l. is: E226584
Drives GT3000 comply with the UL certification requirements provided the following instructions contained are
obeyed.
1. Use only copper bus bars or copper wire cables Class 1 - 65 / 75°C (140/167°F) with the cross-section
specified in this manual as a function of the inverter frame.
2. Rating of the power supply mains shall not exceed:
5KA rms symmetrical, 480V for models SVGTT0P3F to SVGT028F
30KA rms symmetrical, 480 V for models SVGT030 to SVGT470F
30KA rms symmetrical, 480 V for models SVGT200 to SVGT480K
85KA rms symmetrical, 480V for models SVGT520F to SVGT940K
85KA rms symmetrical, 690V for models SVGT640F to SVGT960K
3. Tightening torque and wire range for field wiring terminals are contained in chapter 3A.
4. Distribution fuse sizes are included in chapter 3A.
5. A UL Listed and CSA Certified closed-loop terminal lugs sized for the wire gauge involved must make
Field-wiring connections. Lugs must be attached using the crimp tool specified by the connector
manufacturer.
6. Solid-state motor overload protection is provided in GT3000. The adjustable range is 105% to 250% of full-
load current. For all information about threshold setting, overload cut-in, etc. see chapter 7B.9
7. Solid-state drive output over current and solid-state D.C. short circuit protections are provided in GT3000.
NOTE SVGT470F, SVGT940M, SVGT105-170K 1ND SVGT521K are not certified.
