GT3000 Technical Data
IMGT30017EN 9
2A.7 Cooling
GT3000 (except for SVGT0P3 to 0P6) provides an internal fan. Air intake is from bottom. Refer to the following table when sizing enclosures:
Table 2A.7 Cooling Specifications
Output Current Power Losses Ventilation Cooling Fan Rated Data
Cl.1 Cl.2 Cl.1 Cl.2 Control Capacity Voltage Current
Drive
A A W W W m
3
/h ft
3
/s V A
SVGT0P3F 3.8 2.1 45 22 30 NA NA Not available NA
SVGT0P4F 5.6 3.8 66 45 30 NA NA Not available NA
SVGT0P6F 9.5 5.6 120 66 30 NA NA Not available NA
SVGT008F 12 9.5 165 120 30 66 36 Not available NA
SVGT011F 16 12 225 165 30 100 59 Not available NA
SVGT015F 21 16 276 225 30
100
59 Not available NA
SVGT018F 25 21 330 276 30
100
59 Not available NA
SVGT022F 32 25 450 330 30
100
59 Not available NA
SVGT028F 40 32 555 450 40
100
59 Not available NA
SVGT030F/Y 40 32 555 450 40
100
59 Not available NA
SVGT036F/Y 52 40 660 555 40
100 59 Not available NA
SVGT045F/Y 65 52 900 660 50
280 164 Not available NA
SVGT053F/Y 77 65 1100 900 50
280 164 Not available NA
SVGT066F/Y 96 77 1350 1100 50
280 164 Not available NA
SVGT086F/Y 124 96 1650 1350 60
280 164 Not available NA
SVGT108F/Y 156 124 2250 1650 60
280 164 Not available NA
SVGT125F/Y 180 156 2700 2250 60
500 293
230V 50/60Hz 0,9
SVGT150F/Y 210 180 3300 2700 80 500 293 230V 50/60Hz 0,9
SVGT166F/Y 240 200 3300 2700 80 500 293 230V 50/60Hz 0,9
SVGT200F/Y 302 240 3960 3300 80 800 471 230V 50/60Hz 1.45
SVGT250F/Y 361 302 4800 3960 100 800 471 230V 50/60Hz 1.45
SVGT292F/Y 420 370 6900 6000 100 1400 824 400V/50Hz - 440V/60Hz 3.4 / 4.4
SVGT340F/Y 510 420 7500 6500 100
1400
824 400V/50Hz - 440V/60Hz 3.4 / 4.4
SVGT420F/Y 610 480 9000 7800 100
1400
824 400V/50Hz - 440V/60Hz 3.4 / 4.4
SVGT470F/Y 680 520 10000 7800 100
1400
824 400V/50Hz - 440V/60Hz 3.4 / 4.4
SVGT520F/Y 800 620 10800 8000 200 2x1400 2x824 400V/50Hz - 440V/60Hz (3.4 / 4.4) X 2
SVGT580F/Y 840 740 12150 8500 200
2x1400
2x824 400V/50Hz - 440V/60Hz (3.4 / 4.4) X 2
SVGT670F/Y 1020 840 14000 11000 200
2x1400
2x824 400V/50Hz - 440V/60Hz (3.4 / 4.4) X 2
SVGT780F/Y 1220 960 16400 12500 200
2x1400
2x824 400V/50Hz - 440V/60Hz (3.4 / 4.4) X 2
Three-phase supply voltage 400V, 415V, 440V, 460V, 480V ±10%
SVGT940M/Y 1360 1040 20000 15600 200
2x1400
2x824 400V/50Hz - 440V/60Hz (3.4 / 4.4) X 2
SVGT105K/J 90 76 1500 1350 80 400 235 230V 50/60Hz 0.9
SVGT130K/J 110 90 1800 1500 80 400 235 230V 50/60Hz 0.9
SVGT170K/J 145 110 3400 1800 80 400 235 230V 50/60Hz 0.9
SVGT200K/J 170 135 3900 3400 100 800 471 230V 50/60Hz 1.45
SVGT260K/J 220 180 3600 3000 100 800 471 230V 50/60Hz 1.45
SVGT320K/J 270 210 4400 3500 100 800 471 230V 50/60Hz 1.45
SVGT390K/J 330 260 5400 4300 100 1400 824 400V/50Hz - 440V/60Hz 3.4/4.4
SVGT1480K/J 400 320 6500 5200 100 1400 824 400V/50Hz - 440V/60Hz 3.4/4.4
SVGT521K/J 440 350 7200 5300 100 1400 824 400V/50Hz - 440V/60Hz 3.4/4.4
SVGT640K/J 540 420 8800 7000 200 2x1400 2x824 230V 50/60Hz (1.45) x 2
SVGT780K/J 660 520 10800 8600 200 2x1400 2x824 400V/50Hz - 440V/60Hz (3.4 / 4.4) x 2
Three-phase supply voltage 535V, 575V,
600V, 660V, 690V ±15%
SVGT1960K/J 800 620 13000 10400 200 2x1400 2x824 400V/50Hz - 440V/60Hz (3.4 / 4.4) x 2
% The GT3000 fans are made to provide for losses of the drives only. During the installation in an
enclosure, it is necessary to take into account auxiliary component losses.
% SVGT125-166F/Yand SVGT105-960K/J The user must provide a protection device for the fan.
% SVGT200F-940M/Y Inside the drive there is a Magneto-thermal switch for the fan protection.
