GT3000 Spare Parts
IMGT30017EN 77
GT3000 Spare Parts GT3000 SVGT200F/Y-940M/Y
Description
Catalogue No.
200 250 292 340 420 470 520 580 670 780 940 Q.ty*
Main Control Board SCADAP (D) ELC452584 1 1 1 1 1
(only one type SCADAP (D) 1000001377 1 1 1
per drive) SCADAP (E) ELC452613 1 1 1 1 1 1 1 1 1 1 1
Power Supply Board SPUFA (F/Y) ELC452637 1 1 1 1 1 1 1 1 1 1 1
SPUFA (F.10/Y.10) ELC452638 1 1 1 1 1 1 1 1 1 1
SPUFA (Y.20-21) 1000001492 1 1 1 1 1 1 1
SPUFA (Y.20/21-10) 1000007017 1 1 1 1 1 1
SPUFA (Y.20 parallel) 1000073384 1 1 1 1 1
SPUFA (Y.2010 parallel) 1000073385 1 1 1 1 1
Tuning Board SIZES152 ELC45264901
SIZES182 ELC45264902 1
SIZES216 ELC45264903 1
SIZES292 ELC45264905 1
SIZES340 ELC45264906 1 1
SIZES420 ELC45264907 1
SIZES470 1000087237
1
SIZES520 ELC45264912 2
SIZES580 ELC45264909 2
SIZES670 ELC45264910 2
SIZES780 ELC45264911 2
SIZES940 1000874907
2
Drive Board TPIL40A 1000011605 3 3
TPIL40A 1000011606 3 3
TPIL40A ELC453017 6 6
TPIL40A ELC453018 6 6
TPIL40A 1000011607 3 3 3 6
Power Interface Board INTSCA40A ELC452409 1 1 1 1 1 1
INTSCA ELC452389 1 1 1 1 1
Parallel Board EXPARA ELC452612 1 1 1 1
DC Capacitor 4700 mF 450V ELC409402 12 14 18 22 22 22 32 36 44 44 14
Fan 230V, 1300Mc, 1ph (Kit) 8000001232 1 1 2
380V, 750W, 3ph (kit) 8000001235 1 1 1 1 2 2 2 2 1
220VAC, 4650N, 1ph ELC405417 1 1 1 1 2 2 2 2
IGBT Module 2IGBT 600A, 1200V ELC407337 3 3
2IGBT 800A, 1200V ELC408118 3 6 6 3
2IGBT 1200A, 1200V ELC408949 3 3 3 6 6 6
IGBT Gate Board SGATB ELC452603 3 3 3 3 3 3 6 6 6 6 6 3
Rectifier Module TD210A 1600V 1000004575 3 3
TD250A 1600V 1000004578 3
TD500A, 1600V ELC408989 3 3 3 3 3
TD500A, 1600V ELC409614 3
TZ500A, 1600V 1000005688 3 6
DZ600A, 1600V 1000087131 3 6
TD800A, 1600V ELC409757 3 3
DD600A, 1600V ELC22140703 3 3 3 3 3
Charge rectifier
SKKD100/16, 90
,
ELC402206 1 1 1 1 1 2 2 2 2 2 2
Charge resistor 5R, 350W ELC40862806 1
2R4, 350W ELC40862802 2 2 2 2 2 4 4 4 4 4 2
Precharge TD 310A, 2000V ELC409383 1
Thyristor TD 500A, 1600V ELC408989 1 1 1
(Version-21 only) TD 740A, 2200V ELC409915 1 1 1
Snubber Board GSPIA, >=152kVA ELC452650 1 1 1 1 1 1 1 1 1 1 1 1
Transformer GAUFA ELC452648 1 1 1 1 1 1 1
Brake Unit BRA151-181 ELC45198006 1 1
BRA215-291 ELC45198009 1 1
Current Transducer H.E. current Trans. 500A ELC409382 3 3 1
H.E. current Trans. 750A ELC408990 2 2 2 2 6 6 6 6 6
* Suggested quantity for single drive
