Apollo HD Series User Manual

83
83
Figure 7-11
7.2.2.1 Direction key and 3D positioning key
In Figure 7-10, there are eight direction keys.
In the middle of the eight direction keys, there is a 3D intelligent positioning key.
Click 3D intelligent positioning key, system goes back to the single screen mode. Drag the
mouse in the screen to adjust section size. It can realize PTZ automatically.
7.2.2.2 Speed
System supports eight-level speed. You can select from the dropdown list. Speed 2 is faster than
speed 1.
7.2.2.3 Zoom/Focus/Iris
Here is a sheet for you reference.
Name Function
key
Function Function
key
Function
Zoom
Near
Far
Focus
Near
Far
Iris
close
Open
In Figure 7-11, click PTZ setup button you can see the following interface. See Figure 7-12.
You can click this icon to
display or hide the PTZ
control platform.
3D Intelligent Positioning
Key

Apollo HD Series Specifications

General

Category	DVR
Video Compression	H.264
Hard Drive Capacity	Up to 6TB
Remote Viewing	Yes
Operating System	Embedded Linux
Video Input	4/8/16 channels
Recording Resolution	1080p/720p
Mobile Support	iOS, Android
