Apollo HD Series User Manual

92
92
Parameter Function
Recommended
Bit
Recommended bit rate value according to the resolution and
frame rate you have set.
Color Setting Here you can set video brightness, contrast ness, hue, saturation
and gain.
The value ranges from 0 to 100.Default value is 50. See Figure
7-27.
Cover area
(privacy mask)

Here you can privacy mask the specified video in the monitor
video.

System max supports 8 privacy mask zones.
Time Title

You can enable this function so that system overlays time
information in video window.

OSD transparent value ranges from 0 to 255. 0 means
complete transparent.

You can use the mouse to drag the time tile position.
Channel Title

You can enable this function so that system overlays channel
information in video window.

OSD transparent value ranges from 0 to 255. 0 means
complete transparent.

You can use the mouse to drag the channel tile position.
Copy It is a shortcut menu button. You can copy current channel setup
to one or more channels. The interface is shown as in Figure
7-28.
Save You can click save button after you complete setup for one
channel, or you can complete the whole setups and then click
save button.
Refresh Click this button to get device latest configuration information.
Click copy interface, the interface is shown as in Figure 7-28.
If you have completed the setup for channel 1, you can click 3 to copy current setup to channel 3.
Or you can click 2, 3, and 4 to copy current setup to channel 2, channel 3 and channel 4.
Figure 7-28
7.3.2.3 Schedule
Here you can set different periods for various days. There are max six periods in one day. See
Figure 7-29.

Apollo HD Series Specifications

General

Category	DVR
Video Compression	H.264
Hard Drive Capacity	Up to 6TB
Remote Viewing	Yes
Operating System	Embedded Linux
Video Input	4/8/16 channels
Recording Resolution	1080p/720p
Mobile Support	iOS, Android
