101
ENGLISH
15 Use »
V
« or »
Λ
« to select »My longitude«
and confirm with »
« button. Enter the
defined longitude with »1...0«, select the
»
« on the screen keyboard and confirm
with »
«. Select »Ok« and press »
« to
confirm.
16 Use »
V
« or »
Λ
« to select »My latitude«
and confirm with »
« button. Enter the
defined longitude with »1...0«, select the
»
« on the screen keyboard and confirm
with »
«. Select »Ok« and press »
« to
confirm.
17 Use »
V
« or »
Λ
« to select »Proceed« and
confirm with »
« button.
18 Press »
V
« or »
Λ
« to select the satellite you
want to scan and press »
« to confirm.
19 Use »
V
« or »
Λ
« to select »LNB Settings«
and confirm with »
«.
20 Use »
V
« or »
Λ
« to select »Motor Settings«
and confirm with »
«.
– Motor Settings menu shall be displayed.
Movement Control
Disable Limits
Limit East
Limit West
Store Position
21 Use »
V
« or »
Λ
« to select »Motion Control«
and confirm with »
«.
DETAILED CHANNEL SETTINGS
----------------------------------------------------
22 Select the required elements with »
V
«,
»
Λ
«.
Movement Control
Confirm »Movement Control« with »
«,
select »Nonstop«, »Step«, »Timeout« or
»USALS« with »
V
« or »
Λ
« and confirm
with »
«.
– »Step«: Moves the antenna in the west or
east direction by the specified step size.
– »Nonstop«: Moves the antenna in the
west or east direction constantly.
Step Size
confirm »Step Size« with »
«. Select how
many steps the antenna should rotate with
»1...0«. »Step Size« becomes active when
»Movement Control« is selected as »Step«.
Timeout
Confirm »Timeout« with »
«. Select the
timeout period at which the antenna should
rotate with the »1...0«. »Timeout« becomes
active when »Movement Control« is selected
as »Timeout«.
USALS
Select »USALS« from »Movement Control«
menu. Confirm »Timeout« with »
«. Select
Go To x.x. Angle and confirm with »
«.
Move East
Adjusts the antenna for the selected satel-
lite. Press »
« to move the antenna in the
»East« direction.
Move West
Adjusts the antenna for the selected satel-
lite. Press »
« to move the antenna in the
»West« direction.
Stop Movement
Press »
« to stop the antenna.
Note:
7
When Movement Control is selected as
»USALS«, »Move East«, »Move West« and
»Stop Movement« cannot be seen on the
menu.
