Arduino® Portenta Hat Carrier
10 / 34 Arduino® Portenta Hat Carrier Modified: 25/10/2023
7.2 Full Pinout Table
The full pinout of the Portenta Hat Carrier is available in the following tables sorted by element/connector.
7.2.1 Raspberry Pi® 40-Pins Connector (J5)
Pin
number
Silkscreen Power Net
Portenta HD
Standard Pin
High-Density Pin Interface
1 3V3 +3V3_PORTENTA VCC J2-23, J2-34, J2-43, J2-69
2 5V +5V VIN J1-21, J1-24, J1-32, J1-41, J1-48
3 I2C2 SDA J2-45 I2C 2 SDA
4 5V +5V VIN J1-21, J1-24, J1-32, J1-41, J1-48
5 I2C2 SCL I2C2_SCL J2-47 I2C 2 SCL
6 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
24, J2-33, J2-44, J2-57, J2-70
7 PWM0 PWM_0 J2-59
8 TX3 SERIAL3_TX J2-25 UART 3 TX
9 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
24, J2-33, J2-44, J2-57, J2-70
10 RX3 SERIAL3_RX J2-27 UART 3 RX
11 GPIO2 GPIO2 J2-50
12 I2S CK I2S_CK J1-56 I2S CK
13 GPIO6 GPIO_6 J2-58
14 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
24, J2-33, J2-44, J2-57, J2-70
15 SAI D0 SAI_D0 J2-53 SAI D0
16 SAI CK SAI_CK J2-49 SAI CK
17 3V3 +3V3_PORTENTA VCC J2-23, J2-34, J2-43, J2-69
18 SAI FS SAI_FS J2-51 SAI FS
19 SPI1 COPI SPI1_MOSI J2-42
SPI 1
MOSI
20 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
24, J2-33, J2-44, J2-57, J2-70
21 SPI1 CIPO SPI1_MISO J2-40
SPI 1
MISO
22 PWM1 PWM_1 J2-61
23 SPI1 SCK SPI1_CK J2-38 SPI 1 CK
24 SPI1 CE SPI1_CS J2-36 SPI 1 CS
25 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
24, J2-33, J2-44, J2-57, J2-70
26 PWM2 PWM_2 J2-63
27 I2C0 SDA I2C0_SDA J1-44 I2C 0 SDA
28 I2C0 SCL I2C0_SCL J1-46 I2C 0 SCL
29 RX1 SERIAL1_RX J1-35 UART 1 RX
30 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
24, J2-33, J2-44, J2-57, J2-70
