Page #8 background imageLoading...
Page #8 background image
Arduino® Portenta Hat Carrier
8 / 34 Arduino® Portenta Hat Carrier Modified: 25/10/2023
6 Ratings
6.1 Recommended Operating Conditions
Table 4 provides a comprehensive guideline for the optimal use of the Portenta Hat Carrier, outlining typical
operating conditions and design limits.
Parameter Symbol Min Typ Max Unit
VIN from onboard screw terminal
1
(J9) of the carrier
VIN
TERMINAL
7.0 - 32.0 V
+5 VDC from onboard screw terminal (J9) of the carrier
V5
TERMINAL
- 5.0 - V
USB-C® from the connected Portenta family board
V5
USBC
- 5.0 - V
Current delivered by the carrier
I
CARRIER
- - 1.5 A
+5 VDC from the 40-pin header connector of the carrier
V5
HEADER
- 5.0 - V
Operating ambient temperature
T
OP
-40 - 85 °C
Table 4: Recommended operating conditions of the Portenta Hat Carrier
1
The power supply connected to the onboard screw terminal block powers the carrier, the connected Portenta
family board, and compatible Raspberry Pi® Hats. The onboard screw terminal connector has an integrated reverse
polarity protection.
