Arduino® Portenta Hat Carrier
21 / 34
Arduino® Portenta H
at Carrier
Modified: 25/10/2023
7.5.4 40-Pin Header Connector (J5)
The
Portenta
Hat
Carrier features
a
40-pin
header
connector
as shown
in
Figure 8,
making
it
compatible
with
most
of the Raspberry Pi® Hats available on the market.
Figure 8. Raspberry Pi®-compatible 40-pin header c
onnector
The main interfaces and general-purpose pins available thr
ough this connector include:
SPI (x1)
I2S (x1)
SAI (x1)
5 VDC (x2)
3.3 VDC (x2)
I2C (x2)
UART (without flo
w control) (x2)
PWM (x7)
GND (x8)
GPIO (x26)
