Arduino ASX00049 User Manual

Arduino® Portenta Hat Carrier
14 / 34 Arduino® Portenta Hat Carrier Modified: 25/10/2023
7.2.7 USB-A (J4)
Pin
number
Silkscreen
Power
Net
Portenta HD
Standard Pin
High-Density Pin Interface
1 N/A +5V VIN / USB0_VBUS J1-21, J1-24, J1-32, J1-41, J1-48
2 N/A USB0_D_N J1-28 USB D-
3 N/A USB0_D_P J1-26 USB D+
4 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-24, J2-
33, J2-44, J2-57, J2-70
Table 11: USB-A (J4) pinout
7.2.8 Ethernet (J8)
Pin
number
Silkscreen
Power
Net
Portenta HD
Standard Pin
High-Density Pin Interface
1 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-24,
J2-33, J2-44, J2-57, J2-70
2
ETH CENTER
TAP
3 N/A ETH_D_P J1-13
4 N/A ETH_D_N J1-15
5 N/A ETH_C_P J1-9
6 N/A ETH_C_N J1-11
7 N/A ETH_B_P J1-5
8 N/A ETH_B_N J1-7
9 N/A ETH_A_P J1-1
10 N/A ETH_A_N J1-3
11 N/A ETH_LED2 J1-19
12 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-24,
J2-33, J2-44, J2-57, J2-70
13 N/A N/A
14 N/A ETH_LED1 J1-17
Table 12: Ethernet (J8) pinout
