Arduino® Portenta Hat Carrier
22 / 34
Arduino® Portenta H
at Carrier
Modified: 25/10/2023
7.5.5 16-Pin Header Connector (J6)
The
Portenta
Hat
Carrier has
a
16-pin
connector
as
shown in
Figure
9
to
access multiple
analog,
PWM,
serial
ports,
and power-r
elated pins.
Figure 9. 16-pin header connector
The main interfaces and general-purpose pins that can be accessed via this connector ar
e:
Analog I/O (x8)
PWM (x2)
1x LiCell pin for Portenta'
s RT
C power (x1)
GPIO (x1)
3.3 VDC (x1)
GND (x1)
UART (without flo
w control) (x1)
21
23
