Arduino® Portenta Hat Carrier
15 / 34
Arduino® Portenta H
at Carrier
Modified: 25/10/2023
7.2.9 MicroSD Card Slot (J7)
Pin
number
Silkscreen
Power Net
Portenta HD
Standard Pin
High-Density Pin
Interface
1
N/A
SDC_D2
J1-63
2
N/A
SDC_D3
J1-65
3
N/A
SDC_CMD
J1-57
4
N/A
VDD_SDCARD
VSD
J1-72
5
N/A
SDC_CLK
J1-55
6
N/A
GND
GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-24,
J2-33, J2-44, J2-57, J2-70
7
N/A
SDC_D0
J1-59
8
N/A
SDC_D1
J1-61
CD1
N/A
SDC_CD
J1-67
CD2
N/A
GND
GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-24,
J2-33, J2-44, J2-57, J2-70
T
able 13: MicroSD Car
d Slot (
J7) pinout
