Arduino® Portenta Hat Carrier
26 / 34 Arduino® Portenta Hat Carrier Modified: 25/10/2023
7.5.9 Camera Connector (J10)
The Portenta Hat Carrier, when combined with a Portenta X8, supports MIPI cameras. The latter can be plugged
into the onboard camera connector shown in Figure 13 via a flexible flat cable.
Figure 13. Camera connector of the Portenta Hat Carrier
Some of the potential compatible devices are the following:
OmniVision® OV5645 sensor, like the one used in the Raspberry Pi® Camera Module 1.
Sony® IMX219 sensor, like the one used in the Raspberry Pi® Camera Module 2.
