Arduino ASX00049 User Manual

Arduino® Portenta Hat Carrier
13 / 34 Arduino® Portenta Hat Carrier Modified: 25/10/2023
7.2.5 JTAG Header (J3)
Pin
number
Silkscreen Power Net
Portenta HD
Standard Pin
High-Density Pin Interface
1 N/A +3V3_PORTENTA VCC J2-23, J2-34, J2-43, J2-69
2 N/A JTAG_SWD J1-75 JTAG SWD
3 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
24, J2-33, J2-44, J2-57, J2-70
4 N/A JTAG_SCK J1-77 JTAG SCK
5 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
24, J2-33, J2-44, J2-57, J2-70
6 N/A JTAG_SWO J1-79 JTAG SWO
7 N/A NC NC
8 N/A JTAG_TDI J1-78 JTAG TDI
9 N/A JTAG_TRST J1-80
JTAG
TRST
10 N/A JTAG_RST J1-73 JTAG RST
Table 9: JTAG Header (J3) pinout
7.2.6 MIPI Camera (J10)
Pin
number
Silkscreen Power Net
Portenta HD
Standard Pin
High-Density Pin Interface
1 N/A GND GND J1-22, J1-31, J1-42, J1-47, J1-54
2 N/A CAM_D0_D0_N
J2-16, J2-24, J2-33, J2-44, J2-57, J2-
70
3 N/A CAM_D1_D0_P J2-14
4 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
24, J2-33, J2-44, J2-57, J2-70
5 N/A CAM_D2_D1_N J2-12
6 N/A CAM_D3_D1_P J2-10
7 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
24, J2-33, J2-44, J2-57, J2-70
8 N/A CAM_CK_CK_N J2-20
9 N/A CAM_VS_CK_P J2-18
10 N/A GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-
24, J2-33, J2-44, J2-57, J2-70
11 N/A GPIO_5 J2-56
12 N/A NC NC
13 N/A I2C1_SCL J1-45 I2C 1 SCL
14 N/A I2C1_SDA J1-43 I2C 1 SDA
15 N/A +3V3_PORTENTA VCC J2-23, J2-34, J2-43, J2-69
Table 10: JTAG Header (J3) pinout
