Page #12 background imageLoading...
Page #12 background image
Arduino® Portenta Hat Carrier
12 / 34 Arduino® Portenta Hat Carrier Modified: 25/10/2023
7.2.3 Power Block CAN Bus (J9)
Pin
number
Silkscreen Power Net
Portenta HD
Standard Pin
High-Density Pin Interface
1
VIN 7-
32VDC
INPUT_7V-
32V
2 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-24,
J2-33, J2-44, J2-57, J2-70
3 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-24,
J2-33, J2-44, J2-57, J2-70
4 5V +5V VIN J1-21, J1-24, J1-32, J1-41, J1-48
5 CANH J1-49 (Through U1)
CAN BUS -
CANH
6 CANL J1-51 (Through U1)
CAN BUS -
CANL
Table 7: Power Block CAN Bus (J9) pinout
7.2.4 FAN PWM Header (J11)
Pin
number
Silkscreen
Power
Net
Portenta HD
Standard Pin
High-Density Pin Interface
1 PWM9 PWM_9 J2-68
2 N/A
3 5V +5V VIN J1-21, J1-24, J1-32, J1-41, J1-48
4 GND GND GND
J1-22, J1-31, J1-42, J1-47, J1-54, J2-24, J2-
33, J2-44, J2-57, J2-70
Table 8: FAN PWM Header (J11) pinout
