7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-9
Enable for the transmission of spontaneous signals via the communication
interface.
COMM1: Select. spontan.sig.
003 179
Fig. 3-8, 3-9,
3-10
Selection of signals transmitted via the communication interface, e.g. from
private range of IEC 60870-5-103.
COMM1: Transm.enab.cycl.dat
003 074
Fig. 3-8, 3-9,
3-10
Enabling of cyclic transmission of measured values via the communication
interface.
COMM1: Cycl. data ILS tel.
003 175
Fig. 3-8, 3-9,
3-10
Selection of the measured values transmitted in a user-defined telegram via
the communication interface.
COMM1: Delta V
003 050
Fig. 3-8, 3-9,
3-10
measured voltage value is transmitted via the communication interface if it
differs by the set delta quantity from the last measured value transmitted.
COMM1: Delta I
003 051
Fig. 3-8, 3-9,
3-10
measured current value is transmitted via the communication interface if it
differs by the set delta quantity from the last measured value transmitted.
COMM1: Delta P
003 054
Fig. 3-8, 3-9,
3-10
The active power value is transmitted via the communication interface if it
differs by the set delta quantity from the last measured value transmitted.
COMM1: Delta f
003 052
Fig. 3-8, 3-9,
3-10
The measured frequency is transmitted via the communication interface if it
differs by the set delta quantity from the last measured value transmitted.
COMM1: Delta meas.v.ILS tel
003 150
Fig. 3-8, 3-9,
3-10
The telegram is transmitted if a measured value differs by the set delta
quantity from the last measured value transmitted.
COMM1: Delta t
003 053
Fig. 3-8, 3-9,
3-10
All measured data are transmitted again through the communication
interface after this time period has elapsed – provided that transmission has
not been triggered by the other delta conditions.
COMM1: Delta t (energy)
003 151
Fig. 3-8, 3-9,
3-10
The measured data for active energy and reactive energy are transmitted
through the communication interface after this time has elapsed.
COMM1: Contin. general scan
003 077
Fig. 3-8, 3-9,
3-10
A continuous or background general scan means that the C232 transmits all
settings, signals, and monitoring signals through the communication
interface during slow periods when there is not much activity. This ensures
that there will be data consistency with a connected control system. The
time to be set defines the minimum time difference between two telegrams.
COMM1: Comm. address length
003 201
Fig. 3-9
