7 Settings
(continued)
7-10
C232-302-401/402/403/404-603 / C232/EN M/A23
Setting for the communication address length.
Note:
This setting is hidden unless the IEC 870-5-101 protocol is enabled.
COMM1: Octet 2 comm. addr.
003 200
Fig. 3-9
Setting for the length of the higher-order communication address.
Note:
This setting is hidden unless the IEC 870-5-101 protocol is enabled.
COMM1: Cause transm. length
003 192
Fig. 3-9
Setting for the length of the cause of transmission.
Note:
This setting is hidden unless the IEC 870-5-101 protocol is enabled.
COMM1: Address length ASDU
003 193
Fig. 3-9
Setting for the length of the common address for identification of telegram
structures.
Note:
This setting is hidden unless the IEC 870-5-101 protocol is enabled.
(ASDU: Application Service Data Unit).
COMM1: Octet 2 addr. ASDU
003 194
Fig. 3-9
Setting for the length of the common higher-order address for identification
of telegram structures.
Note:
This setting is hidden unless the IEC 870-5-101 protocol is enabled.
(ASDU: Application Service Data Unit).
COMM1: Addr.length inf.obj.
003 196
Fig. 3-9
Setting for the length of the address for information objects.
Note:
This setting is hidden unless the IEC 870-5-101 protocol is enabled.
COMM1: Oct.3 addr. inf.obj.
003 197
Fig. 3-9
Setting for the length of the higher-order address for information objects.
Note:
This setting is hidden unless the IEC 870-5-101 protocol is enabled.
COMM1: Inf.No.<->funct.type
003 195
Fig. 3-9
Setting specifying whether information numbers and function type shall be
reversed in the object address.
Note:
This setting is hidden unless the IEC 870-5-101 protocol is enabled.
COMM1: Time tag length
003 198
Fig. 3-9
Setting for the time tag length.
Note:
This setting is hidden unless the IEC 870-5-101 protocol is enabled.
