7 Settings
(continued)
7-12
C232-302-401/402/403/404-603 / C232/EN M/A23
MODBUS registers in the range 30301 to 30400 are assigned to the
selected measured values. Assignment is made in the order of selection.
This means that the first measured value is given the register no. 30301, the
second the register no. 30302, etc.
Note:
This setting is hidden unless the MODBUS protocol is enabled.
COMM1: Reg.asg. sel. param.
003 213
Fig. 3-11
MODBUS registers in the range 40301 to 40400 are assigned to the
selected parameters. Assignment is made in the order of selection. This
means that the first parameter is given the register no. 40301, the second
the register no. 40302, etc.
Note:
This setting is hidden unless the MODBUS protocol is enabled.
COMM1: Delta t (MODBUS)
003 152
Fig. 3-11
All MODBUS registers are transmitted again through the communication
interface after this time has elapsed.
Note:
This setting is hidden unless the MODBUS protocol is enabled.
