7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-13
COMM1: Autom.event confirm.
003 249
Fig. 3-11
Setting specifying whether an event must be confirmed by the master in
order for an event to be deleted from the 'event queue'.
Note:
This setting is hidden unless the MODBUS protocol is enabled.
COMM1: Phys. Charact. Delay
003 241
Fig. 3-12
Number of bits that must pass between the receipt of the 'request' and the
start of sending the 'response'.
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
COMM1: Phys. Char. Timeout
003 242
Fig. 3-12
Number of bits that may be missing from the telegram before receipt is
terminated.
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
COMM1: Link Confirm. Mode
003 243
Fig. 3-12
Setting for the acknowledgment mode of the link layer.
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
COMM1: Link Confirm.Timeout
003 244
Fig. 3-12
Setting for the time period within which the master must acknowledge at the
link layer.
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
COMM1: Link Max. Retries
003 245
Fig. 3-12
Number of repetitions that are carried out on the link layer if errors have
occurred during transmission (such as failure to acknowledge).
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
COMM1: Appl.Confirm.Timeout
003 246
Fig. 3-12
Setting for the time period within which the master must acknowledge at the
application layer.
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
COMM1: Appl. Need Time Del.
003 247
Fig. 3-12
Time interval within which the slave requests time synchronization cyclically
from the master.
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
COMM1: Ind./cl. bin. inputs
003 232
Fig. 3-12
Selection of data points and data classes for object 1 – binary inputs.
Assignment of indices is made in the order of selection, beginning with 0.
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
