7 Settings
(continued)
7-14
C232-302-401/402/403/404-603 / C232/EN M/A23
COMM1: Ind./cl. bin.outputs
003 233
Fig. 3-12
Selection of data points and data classes for object 10 – binary outputs.
Assignment of indices is made in the order of selection, beginning with 0.
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
COMM1: Ind./cl. bin. count.
003 234
Fig. 3-12
Selection of data points and data classes for object 20 – binary counters.
Assignment of indices is made in the order of selection, beginning with 0.
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
COMM1: Ind./cl. analog inp.
003 235
Fig. 3-12
Selection of data points and data classes for object 30 – analog inputs.
Assignment of indices is made in the order of selection, beginning with 0.
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
COMM1: Ind./cl. analog outp
003 236
Fig. 3-12
Selection of data points and data classes for object 40 – analog outputs.
Assignment of indices is made in the order of selection, beginning with 0.
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
COMM1: Delta meas.v. (DNP3)
003 250
Fig. 3-12
Initialization value of threshold values for transmission of measured values
in object 30. The threshold values can be changed separately by the
master for each measured value by writing to object 34, 'analog input
reporting deadband'.
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
COMM1: Delta t (DNP3)
003 248
Fig. 3-12
Cycle time for updating DNP object 30 (analog inputs).
Note:
This setting is hidden unless the DNP 3.0 protocol is enabled.
"Logical" communication
interface 2
COMM2: Function group COMM2
056 057
Canceling function group COMM2 or including it in the configuration. If the
function group is cancelled from the configuration, then all associated
settings and signals are hidden, with the exception of this setting.
COMM2: General enable USER
103 170
Fig. 3-14
Disabling or enabling "logical" communication interface 2.
COMM2: Line idle state
103 165
Fig. 3-14
Setting for the line idle state indication.
COMM2: Baud rate
103 071
Fig. 3-14
Baud rate of the communication interface.
COMM2: Parity bit
103 171
Fig. 3-14
Set the same parity that is set at the interface of the control system
connected to the C232.
