7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-15
COMM2: Dead time monitoring
103 176
Fig. 3-14
The C232 monitors telegram transmission to make sure that no excessive
pause occurs within a telegram. This monitoring function can be disabled if
it is not required.
Note: This setting is only necessary for modem transmission.
COMM2: Mon. time polling
103 202
Fig. 3-14
The time between two polling calls from the communication master must be
less than the time set here.
COMM2: Octet comm. address
103 072
Fig. 3-14
The communication address and the ASDU address are used to identify the
device in communication via the interface. An identical setting must be
selected for both addresses.
The abbreviation ASDU stands for ‘Application Service Data Unit’.
COMM2: Name of manufacturer
103 161
Fig. 3-14
Setting for the name of the manufacturer.
Note: This setting can be changed to ensure compatibility.
COMM2: Octet address ASDU
103 073
Fig. 3-14
The communication address and the ASDU address are used to identify the
device in communication via the interface. An identical setting must be
selected for both addresses.
The abbreviation ASDU stands for ‘Application Service Data Unit’.
COMM2: Spontan. sig. enable
103 177
Fig. 3-14
Enable for the transmission of spontaneous signals via the communication
interface.
Note: This setting is hidden unless an IEC 870-5 protocol is enabled.
COMM1: Select. spontan.sig.
003 179
Fig. 3-14
Selection of signals transmitted via the communication interface, e.g. from
private range of IEC 60870-5-103.
COMM2: Transm.enab.cycl.dat
103 074
Fig. 3-14
Enabling of cyclic transmission of measured values via the communication
interface.
COMM2: Cycl. data ILS tel.
103 175
Fig. 3-14
Selection of the measured values transmitted in a user-defined telegram via
the communication interface.
COMM2: Delta V
103 050
Fig. 3-14
A
measured voltage value is transmitted via the communication interface if it
differs by the set delta quantity from the last measured value transmitted.
COMM2: Delta I
103 051
Fig. 3-14
A measured current value is transmitted via the communication interface if it
differs by the set delta quantity from the last measured value transmitted.
COMM2: Delta P
103 054
Fig. 3-14
The active power value is transmitted via the communication interface if it
differs by the set delta quantity from the last measured value transmitted.
COMM2: Delta f
103 052
Fig. 3-14
The measured frequency is transmitted via the communication interface if it
differs by the set delta quantity from the last measured value transmitted.
