7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-19
Measured data input
MEASI: Function group MEASI
056 030
Canceling function group MEASI or including it in the configuration. If the
function group is cancelled from the configuration, then all associated
settings and signals are hidden, with the exception of this setting.
MEASI: General enable USER
011 100
Fig. 3-17
Disabling or enabling analog measured data input.
MEASI: Enable IDC p.u.
037 190
Fig. 3-20
Setting for the minimum current that must flow in order for the C232 to
display a measured value > 0 (zero suppression).
MEASI: IDC< open circuit
037 191
Fig. 3-20
If the input current falls below the set threshold, the C232 will issue an ‘open
circuit’ signal.
MEASI: IDC 1
037 150
Fig. 3-20
MEASI: IDC 2
037 152
Fig. 3-20
MEASI: IDC 3
037 154
Fig. 3-20
MEASI: IDC 4
037 156
Fig. 3-20
MEASI: IDC 5
037 158
Fig. 3-20
MEASI: IDC 6
037 160
Fig. 3-20
MEASI: IDC 7
037 162
Fig. 3-20
MEASI: IDC 8
037 164
Fig. 3-20
MEASI: IDC 9
037 166
Fig. 3-20
MEASI: IDC 10
037 168
Fig. 3-20
MEASI: IDC 11
037 170
Fig. 3-20
MEASI: IDC 12
037 172
Fig. 3-20
MEASI: IDC 13
037 174
Fig. 3-20
MEASI: IDC 14
037 176
Fig. 3-20
MEASI: IDC 15
037 178
Fig. 3-20
MEASI: IDC 16
037 180
Fig. 3-20
MEASI: IDC 17
037 182
Fig. 3-20
MEASI: IDC 18
037 184
Fig. 3-20
MEASI: IDC 19
037 186
Fig. 3-20
MEASI: IDC 20
037 188
Fig. 3-20
Setting for the input current that will correspond to a linearized value that
has been set accordingly.
