7 Settings
(continued)
7-20
C232-302-401/402/403/404-603 / C232/EN M/A23
MEASI: IDC,lin 1
037 151
Fig. 3-20
MEASI: IDC,lin 2
037 153
Fig. 3-20
MEASI: IDC,lin 3
037 155
Fig. 3-20
MEASI: IDC,lin 4
037 157
Fig. 3-20
MEASI: IDC,lin 5
037 159
Fig. 3-20
MEASI: IDC,lin 6
037 161
Fig. 3-20
MEASI: IDC,lin 7
037 163
Fig. 3-20
MEASI: IDC,lin 8
037 165
Fig. 3-20
MEASI: IDC,lin 9
037 167
Fig. 3-20
MEASI: IDC,lin 10
037 169
Fig. 3-20
MEASI: IDC,lin 11
037 171
Fig. 3-20
MEASI: IDC,lin 12
037 173
Fig. 3-20
MEASI: IDC,lin 13
037 175
Fig. 3-20
MEASI: IDC,lin 14
037 177
Fig. 3-20
MEASI: IDC,lin 15
037 179
Fig. 3-20
MEASI: IDC,lin 16
037 181
Fig. 3-20
MEASI: IDC,lin 17
037 183
Fig. 3-20
MEASI: IDC,lin 18
037 185
Fig. 3-20
MEASI: IDC,lin 19
037 187
Fig. 3-20
MEASI: IDC,lin 20
037 189
Fig. 3-20
Setting for the linearized current that will correspond to an input current that
has been set accordingly.
MEASI: Scaled val. IDC,lin1
037 192
Fig. 3-21
Setting for the scaled value of IDC,lin 1.
MEASI: Scaled val.IDC,lin20
037 193
Fig. 3-21
Setting for the scaled value of IDC,lin 20.
