7 Settings
(continued)
7-22
C232-302-401/402/403/404-603 / C232/EN M/A23
OUTP: Fct. assignm. K 201
157 002
Fig. 3-22
OUTP: Fct. assignm. K 202
157 006
OUTP: Fct. assignm. K 203
157 010
OUTP: Fct. assignm. K 204
157 014
OUTP: Fct. assignm. K 205
157 018
OUTP: Fct. assignm. K 206
157 022
OUTP: Fct. assignm. K 207
157 026
OUTP: Fct. assignm. K 208
157 030
OUTP: Fct. assignm. K 209
157 034
OUTP: Fct. assignm. K 210
157 038
OUTP: Fct. assignm. K 211
157 042
OUTP: Fct. assignm. K 212
157 046
OUTP: Fct. assignm. K 213
157 050
OUTP: Fct. assignm. K 214
157 054
Assignment of functions to output relays.
OUTP: Oper. mode K 201
157 003
Fig. 3-22
OUTP: Oper. mode K 202
157 007
OUTP: Oper. mode K 20
157 011
OUTP: Oper. mode K 204
157 015
OUTP: Oper. mode K 205
157 019
OUTP: Oper. mode K 206
157 023
OUTP: Oper. mode K 207
157 027
OUTP: Oper. mode K 208
157 031
OUTP: Oper. mode K 209
157 035
OUTP: Oper. mode K 210
157 039
OUTP: Oper. mode K 211
157 043
OUTP: Oper. mode K 212
157 047
OUTP: Oper. mode K 213
157 051
OUTP: Oper. mode K 214
157 055
Selection of operating mode for output relays.
