LED indicators
The C232 has a total of 13 LED indicators for parallel display of binary signals. The
Address List in the Appendix gives information about the configuration options for all
LED indicators. The following table provides an overview.
LED indicator Description on
the label strip
as supplied
Configuration
H 1 ‘HEALTHY’ Not configurable. H 1 signals the operational readiness of the device
(supply voltage present).
H 17 ‘EDIT MODE’ Not configurable. H 17 signals the fact that the user is in the ‘EDIT
MODE’. In this mode, parameter values can be changed. (See the
section entitled ‘Display and Keypad’ in Chapter 6.)
H 2 ‘OUT OF SERVICE’ Permanently assigned to the function MAIN: Blocked/faulty.
H 3 ‘ALARM’ Permanently assigned to the function SFMON: Warning (LED).
H 4 ‘TRIP’ The factory-set configuration is shown in the Terminal Connection
Diagrams. These diagrams are found in the appendix to this manual or
in the Supporting Documents shipped with the device.
H 5 to H 12 ---- The user has the option of assigning functions to these LED indicators.
The arrangement of the LED indicators on the local control panel is illustrated in the
dimensional drawings of Chapter 4.
An operating mode can be defined for each LED indicator. Depending on the selected
operating mode, the output relay will operate in either energize-on-signal (ES) mode
(‘open-circuit principle’) or normally-energized (NE) mode (‘closed-circuit principle’) and
in either latching or non-latching mode. For LED indicators operating in latching mode,
the operating mode setting also determines when latching will be canceled.
LED: Fct. assignm. H 2
085 001
Fig. 3-24
Display of the function assigned to LED indicator H 2 (‘OUT OF SERVICE’).
The MAIN: Blocked/faulty function is permanently assigned to this
LED.
LED: Fct. assignm. H 3
085 004
Display of the function assigned to LED indicator H 3 (‘ALARM’).
The SFMON: Warning (LED) function is permanently assigned to
this LED.
LED: Fct. assignm. H 4
085 007
LED: Fct. assignm. H 5
085 010
LED: Fct. assignm. H 6
085 013
LED: Fct. assignm. H 7
085 016
LED: Fct. assignm. H 8
085 019
LED: Fct. assignm. H 9
085 022
LED: Fct. assignm. H 10
085 025
LED: Fct. assignm. H 11
085 028
LED: Fct. assignm. H 12
085 031
Assignment of functions to LED indicators.
