7 Settings
(continued)
7-24
C232-302-401/402/403/404-603 / C232/EN M/A23
LED: Operating mode H 2
085 002
Fig. 3-24
LED: Operating mode H 3
085 005
LED: Operating mode H 4
085 008
LED: Operating mode H 5
085 011
LED: Operating mode H 6
085 014
LED: Operating mode H 7
085 017
LED: Operating mode H 8
085 020
LED: Operating mode H 9
085 023
LED: Operating mode H 10
085 026
LED: Operating mode H 11
085 029
LED: Operating mode H 12
085 032
Selection of operating mode for LED indicators.
Main funcions
MAIN: Chann.assign.COMM1/2
003 169
Fig. 3-60
Assigment of the “logical” communication interface to the physical
communication port..
MAIN: Type of bay
220 000
Fig. 3-28
Configuration of a bay type.
MAIN: Customized bay type
221 062
Fig. 3-28
If a user-specific (customized) bay type has been loaded, ist bay type No.
will be displayed. If no customized bay type has been loaded, the number
‘0’ will be displayed.
Fault recording
FT_RC: Rec. analog chann. 1
035 160
FT_RC: Rec. analog chann. 2
035 161
FT_RC: Rec. analog chann. 3
035 162
FT_RC: Rec. analog chann. 4
035 163
FT_RC: Rec. analog chann. 7
035 166
The user specifies the channel on which each physical variable is recorded.
Canceling a function
The user can adapt the device to the requirements of a particular high- or medium-
voltage system by including the relevant functions in the device configuration and
canceling all others (removing them from the device configuration).
The following conditions must be met before canceling a function:
The function in question must be disabled.
None of the functions of the function to be canceled may be assigned to a binary
input.
None of the signals of the function may be assigned to a binary output or an LED
indicator.
None of the signals of the function may be linked to other signals by way of an ‘m out
of n’ parameter.
The function to which a parameter, a signal, or a measured value belongs is defined by
the function group descriptor (example: ‘LIMIT’).
