Single-pole signals
SIG_1: Function group SIG_1
249 250
Canceling function group SIG_1 or including it in the configuration. If the
function group is cancelled from the configuration, then all associated
settings and signals are hidden, with the exception of this setting.
SIG_1: Signal S001 config.
226 007
Fig. 3-115
SIG_1: Signal S002 config.
226 015
SIG_1: Signal S003 config.
226 023
SIG_1: Signal S004 config.
226 031
SIG_1: Signal S005 config.
226 039
SIG_1: Signal S006 config.
226 047
SIG_1: Signal S007 config.
226 055
SIG_1: Signal S008 config.
226 063
SIG_1: Signal S009 config.
226 071
SIG_1: Signal S010 config.
226 079
SIG_1: Signal S011 config.
226 087
SIG_1: Signal S012 config.
226 095
SIG_1: Signal S013 config.
226 103
SIG_1: Signal S014 config.
226 111
SIG_1: Signal S015 config.
226 119
SIG_1: Signal S016 config.
226 127
SIG_1: Signal S017 config.
226 135
SIG_1: Signal S018 config.
226 143
SIG_1: Signal S019 config.
226 151
SIG_1: Signal S020 config.
226 159
Canceling signals S001 to S040 or including them in the configuration. If a
signal is cancelled, then all associated settings and signals are hidden, with
the exception of this setting.
Tap changers
TAPCH: Function group TAPCH
249 253
Canceling function group TAPCH or including it in the configuration. If the
function group is cancelled from the configuration, then all associated
settings and signals are hidden, with the exception of this setting.
TAPCH: TapCh 1 config.
249 119
Fig. 3-118
Canceling TAPCH functions or including them in the configuration. If the
function is cancelled from the configuration, then all associated settings and
signals are hidden, with the exception of this setting.
Binary counters
COUNT: Function group COUNT
217 047
Canceling function group COUNT or including it in the configuration. If the
function group is cancelled from the configuration, then all associated
settings and signals are hidden, with the exception of this setting.
