7 Settings
(continued)
C232-302-401/402/403/404-603 / C232/EN M/A23 7-27
DEV01: Funct. type, command
210 032
DEV02: Funct. type, command
210 082
DEV03: Funct. type, command
210 132
DEV04: Funct. type, command
210 182
DEV05: Funct. type, command
210 232
DEV06: Funct. type, command
211 032
DEV07: Funct. type, command
211 082
DEV08: Funct. type, command
211 132
DEV09: Funct. type, command
211 182
DEV10: Funct. type, command
211 232
Setting for the function type of the command.
Note:
If the IEC 870-5-101 communication protocol has been set, then the ‘low
address’ of the information object will be defined by this setting. If the ILS-C
protocol has been set, then this setting will correspond to DN2.
DEV01: Inform. No., command
210 033
DEV02: Inform. No., command
210 083
DEV03: Inform. No., command
210 133
DEV04: Inform. No., command
210 183
DEV05: Inform. No., command
210 233
DEV06: Inform. No., command
211 033
DEV07: Inform. No., command
211 083
DEV08: Inform. No., command
211 133
DEV09: Inform. No., command
211 183
DEV10: Inform. No., command
211 233
Setting for the information number of the signal.
Note:
If the IEC 870-5-101 communication protocol has been set, then the ‘high’
address’ of the information object will be defined by this setting. If the ILS-C
protocol has been set, then this setting will correspond to DN3.
Single-pole commands
CMD_1: Function group CMD_1
249 252
Canceling function group CMD1 or including it in the configuration. If the
function group is cancelled from the configuration, then all associated
settings and signals are hidden, with the exception of this setting.
CMD_1: Command C001 config.
200 004
CMD_1: Command C002 config.
200 009
CMD_1: Command C003 config.
200 014
CMD_1: Command C004 config.
200 019
CMD_1: Command C005 config.
200 024
CMD_1: Command C006 config.
200 029
CMD_1: Command C007 config.
200 034
CMD_1: Command C008 config.
200 039
CMD_1: Command C009 config.
200 044
CMD_1: Command C010 config.
200 049
CMD_1: Command C011 config.
200 054
CMD_1: Command C012 config.
200 059
Canceling commands C001 to C026 or including them in the configuration.
If a command is cancelled, then all associated settings and signals are
hidden, with the exception of this setting.
